Asus ExpertCenter PN53-BBR575HD, AMD Ryzen 5 7535H, 2xDDR5 SO-DIMM, 2xM.2+SATA3, 2.5Gbe LAN, WiFi 6E, Bluetooth 5.2
ASUS 90MR00S2-M001E0
Ultra-compact mini PC with AMD Ryzen™ 7000 and 6000 H Series Processors and AMD Radeon ™ Graphics, supports Quad-4K displays and 8K resolution, 2x PCIe® Gen4x4 M.2 NVMe™ SSD, 2.5 Gb LAN, WiFi 6E
• Powered by the latest AMD Ryzen™ 7000 and 6000H Series Processor with Radeon™ graphics
• Quad-4K displays support and 8K UHD support**
• Support 7 USB ports, including 2 x USB 4 Type C ports, and on-board dual HDMI ports
• Features Two-Way AI Noise Cancelation to provide crystal-clear online voice communication
• Support DisplayPort 1.4 & Power Delivery input through rear USB Type C port
• Onboard 2.5GbE LAN delivering faster Ethernet connectivity
• Multi-storage design, support up to up to 2x M.2 PCIe Gen4x4 SSD and 1x HDD
• Integrated Wi-Fi 6E and Bluetooth for easy cordless connections
• Configurable Ports support DP1.4/VGA/COM/HDMI options
• 24/7 reliability — Extensively tested to ensure long-term dependability
• Powered by the latest AMD Ryzen™ 7000 and 6000H Series Processor with Radeon™ graphics
• Quad-4K displays support and 8K UHD support**
• Support 7 USB ports, including 2 x USB 4 Type C ports, and on-board dual HDMI ports
• Features Two-Way AI Noise Cancelation to provide crystal-clear online voice communication
• Support DisplayPort 1.4 & Power Delivery input through rear USB Type C port
• Onboard 2.5GbE LAN delivering faster Ethernet connectivity
• Multi-storage design, support up to up to 2x M.2 PCIe Gen4x4 SSD and 1x HDD
• Integrated Wi-Fi 6E and Bluetooth for easy cordless connections
• Configurable Ports support DP1.4/VGA/COM/HDMI options
• 24/7 reliability — Extensively tested to ensure long-term dependability
Art.nr: 11437
Beställningsvara (ber. 2025-10-09)
{$antal} {$enhet} i fjärrlager
5 390 kr
Produktspecifikation
Processor
| Tillverkare | AMD |
| Processorfamilj | AMD Ryzen 5 |
| Processor | 7535H |
| Processorkärnor | 6 |
| L3-cache | 16 MB |
| Processortrådar | 12 |
| Processorfrekvens | 3,3 GHz |
| Processorboostfrekvens | 4,55 GHz |
| Processorns cache | 19 MB |
Grafiken
| Ombord grafikkort modell | AMD Radeon 660M |
Minne
| Antal minnesplatser | 2 |
| Minnestyper som stöds | DDR5-SDRAM |
| Maximalt internminne | 32 GB |
| Minnesplatser, typ | SO-DIMM |
| Minnets hastigheter | 4800 MHz |
Nätverk
| Wi-Fi-standard | Wi-Fi 6E (802.11ax) |
| Bluetooth-version | 5.2 |
| Bluetooth | Ja |
| Nätverksansluten (Ethernet) | Ja |
| LAN-styrenhet | Realtek RTL8125B-CG |
| Wi-Fi | Ja |
| Wi-Fi-standarder | Wi-Fi 6E (802.11ax) |
| Koppar Ethernet-kablar teknik | 2500BASE-T |
Anslutningar
| Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar | 5 |
| HDMI-version | 2.1 |
| Hörlursutgångar | 1 |
| Uttag för mikrofon/linje in | Ja |
| Antal HDMI-portar | 2 |
| USB 4 Gen 2x2, antal portar | 2 |
| Antal LAN (RJ-45) anslutningar | 1 |
Design
| Produktens färg | Svart |
| Chassityp | 0,92L storlek PC |
| Kylning typ | Aktiv |
| Typ av kabellåsanslutning | Kensington |
Lagringsmedia
| Antal lagringsenheter som stöds | 3 |
| Lagringsenhetens gränssnitt | PCI Express, Serial ATA III |
| Storlekar som stöds på lagringsenhet | 2.5", M.2 |
Strömtillförsel
| Nätaggregatstyp | Extern nätadapter |
Vikt & dimension
| Bredd | 120 mm |
| Djup | 130 mm |
| Höjd | 58 mm |
| Höjd | 68 mm |
| Vikt | 900 g |
Fabrikat
| Tillverkare | ASUS |
| SKU | 90MR00S2-M001E0 |
Processor
| Tillverkare | AMD |
| Processorfamilj | AMD Ryzen 5 |
| Processor | 7535H |
| Processorkärnor | 6 |
| L3-cache | 16 MB |
| Processortrådar | 12 |
| Processorfrekvens | 3,3 GHz |
| Processorboostfrekvens | 4,55 GHz |
| Processorns cache | 19 MB |
Grafiken
| Ombord grafikkort modell | AMD Radeon 660M |
Minne
| Antal minnesplatser | 2 |
| Minnestyper som stöds | DDR5-SDRAM |
| Maximalt internminne | 32 GB |
| Minnesplatser, typ | SO-DIMM |
| Minnets hastigheter | 4800 MHz |
Nätverk
| Wi-Fi-standard | Wi-Fi 6E (802.11ax) |
| Bluetooth-version | 5.2 |
| Bluetooth | Ja |
| Nätverksansluten (Ethernet) | Ja |
| LAN-styrenhet | Realtek RTL8125B-CG |
| Wi-Fi | Ja |
| Wi-Fi-standarder | Wi-Fi 6E (802.11ax) |
| Koppar Ethernet-kablar teknik | 2500BASE-T |
Anslutningar
| Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar | 5 |
| HDMI-version | 2.1 |
| Hörlursutgångar | 1 |
| Uttag för mikrofon/linje in | Ja |
| Antal HDMI-portar | 2 |
| USB 4 Gen 2x2, antal portar | 2 |
| Antal LAN (RJ-45) anslutningar | 1 |
Design
| Produktens färg | Svart |
| Chassityp | 0,92L storlek PC |
| Kylning typ | Aktiv |
| Typ av kabellåsanslutning | Kensington |
Lagringsmedia
| Antal lagringsenheter som stöds | 3 |
| Lagringsenhetens gränssnitt | PCI Express, Serial ATA III |
| Storlekar som stöds på lagringsenhet | 2.5", M.2 |
Strömtillförsel
| Nätaggregatstyp | Extern nätadapter |
Vikt & dimension
| Bredd | 120 mm |
| Djup | 130 mm |
| Höjd | 58 mm |
| Höjd | 68 mm |
| Vikt | 900 g |
Fabrikat
| Tillverkare | ASUS |
| SKU | 90MR00S2-M001E0 |
